Model

XCV-2000B2

ICU Ventilator

XCV-2000B3

ICU Ventilator

Display mode

10.4”

10.4”

Mode

VCV,PCV,SIMV,PSV,PSV+SIMV,CPAP

Function

PEEP,SIGH, IRV, IP,Standby

Tidal volume

20~1800 ml

20~1800 ml

Rate

2~120bpm

2~120bpm

SIMV rate

2~120bpm

2~120bpm

I:E

4:1~1:8

4:1~1:8

Inspiratory trigger pressure

-1.0~1.0 kPa

-1.0~1.0 kPa

PEEP

0~25 cmH2O

0~25 cmH2O

Pressure range

3~50 cmH2O

3~50 cmH2O

Pressure limitation

5~60 cmH2O

5~60 cmH2O

Pressure slope

1~10 gear

1~10 gear

Flow rate setting

1~10 gear

1~10 gear

Time control

1~10s

1~10s

SIGH

1.5 times the inspiratory time (60-120 adjustable)

Inspiratory platform

0~50%

0~50%

Oxygen concentration

45%~100%

21%~100%

Parameters for ventilation monitoring

Expired tidal volume, Inhale tidal volume, minute ventilation volume, IPPV rate, SIMV rate, total respiratory rate, autonomous inspiratory rate, I/E, peak pressure of airway, average pressure, PEEP, inspiratory trigger pressure, Inspiratory platform, oxygen concentration, battery capacity, pressure - time waveform, flow rate - time waveform, flow-volume loop, pressure-volume loop

Power

220V±10%, 50Hz±1Hz. UPS, Storage battery

220V±10%, 50Hz±1Hz. UPS, Storage battery

Mechanical Arms

YES

YES

Compressor

/

YES
